Kito SER Heavy Duty Electric Chain Hoist - 1/2 Tonne
Capacity: 1/2 Tonne Connection: Hook Mount Hoist Lifting Speed: 15 ft/min
Standard pendant hangs approximately 4ft. above the hoist's fully extended bottom hook
Standard power supply cord is 15 ft. No price deductions for shorter lengths.
STANDARDS
CSA approved with CSA log
Meets ASME B30.16
ASME 4
IP55 dust-tight and watertight environmental protection
At rated capacity, load-bearing parts are only stressed to 25% of their limit
OPTIONS
Plastic, canvas, or steel chain containers
Lift lengths can be customized to suit requirements
Plain or geared trolley mount
**Contact us directly to add special options
BODY
Die-cast aluminum frame
Completely sealed body
Low headroom profile
GEARS
Induction-hardened, durable alloy steel helical and spur gears submersed in an oil bath
LOAD CHAIN
Grade 80
Nickel-plated and corrosion-resistant
CHAIN GUIDE
Long-lasting, heavy-duty cast iron construction, easily replaced without disassembling hoist
HOOKS
Forged carbon steel opens gradually without fracturing under excessive loads. Bottom hook swivels 360 degrees
Self-closing top and bottom hooks with heavy-duty hook latch
CONTROLS
Located on one central electrical panel
Control Voltage: 110 volts
PUSH BUTTON STATION
Impact-resistant plastic with molded strain relief to avoid damage from pulling on the push button cord
IP65 dust-tight and watertight environmental protection
BEARINGS
High-quality, anti-friction ball and roller design
BRAKE
Durable and reliable pull-rotor motor brake
MOTOR
Single phase
Totally enclosed fan cooled (TEFC) squirrel cage
Re-connectable Voltage:115/230-1-60
Insulation class B
Hertz: 60
60 minute, H4 rated, fan cooled for demanding applications
OVERLOAD PROTECTION
Long-life friction clutch protects hoist from excessive overload damage
OVERTRAVEL PROTECTION
Upper limit switch disables controls when load block reaches travel limit to prevent overwinding
OPERATING CONDITIONS
Recommended for -20˚ to +40˚ C and humidity of 85% or lower
